Overview of ACM Panel
A HIGHLY DURABLE, FIRE-RESISTANT SOLUTION FOR EXTERIOR WALL DECORATION
Wise offers ACM panels that are greater rigidity, superior flatness, and more stable physical properties. They are ideal for high-rise buildings, projects with strict fire regulations, designs demanding extreme flatness and a modern aesthetic.
What’s an ACM Panel?
THE BASICS OF ALUMINUM COMPOSITE METAL PANEL
ACM PANEL is composed of a metal plate and a mineral fiber core or fire-resistant core. The stability of the core material provides enhanced overall resistance to deformation, increased durability, and superior fire resistance.
Superior Physical Properties
ACM panels are suitable for processes like bending and shallow forming. They can be fabricated into larger sections for a seamless and impressive visual effect.
Wide Range of Finishes
ACM panels achieve a metallic, technologically advanced look through various anodizing processes, offering finishes like silver mirror, bead-blasted matte champagne gold, and black brushed stainless steel.
Excellent Sound Insulation
The Mineral core materials have better airborne sound insulation properties, which helps reduce external noise interference.
Applications of ACM Panel
VERSATILE USES ACROSS INDUSTRIES AND DESIGN
ACM PANEL is suitable for projects with mandatory fire safety regulations, coastal/highland areas with high wind pressure, and projects where the budget focuses more on long-term value.
High-end architectural curtain wall
Ideal for office buildings, airport terminals, and cultural venues. They meet modern architectural aesthetics while significantly reducing building load and complying with stringent fire protection standards.
Large-span building entrance
Perfect for hotel lobbies and car showrooms, offering a lightweight yet robust design with a simple, elegant, and safe appearance.
Interior decoration & partitions
For conference room ceilings, banks, and hotels, we provide modern interior decorate that are durable, smooth, easy to clean, safe, and eco-friendly, combining aesthetics with practical functionality.
Specifications
Technical Details
Material: AA3003/AA5005
Thickness: 4mm-6mm
Width: 1220mm-1500mm
Length: 2440mm-6000mm
Core: Non-toxic Fire-resistant (FR) Core
Non-combustible Mineral Core
Aluminum Corrugated Core
Aluminum Honeycomb Core
FR Grades: B1/A2(according to EN 13501:2018 & GB/T8624:2012)
Skin Thickness: 0.20mm~0.60mm
Finish: PE、PVDF、Anodized、Galvanized Iron
Textures: Brushed/ Bead Blasted/ Mirror Polished
Colors: Solid colors、Wood-grain、Stone-grain、Fabric Pattern
Packing: Vertical Placement+Protective Film+Wooden Package
Surface Finishes for ACM Panel
ENHANCING DURABILITY WITH AESTHETIC APPEAL
Our ACM panels feature excellent surface finishes that improve both their appearance and strength. Options include PE (vivid color), PVDF (high durability), Anodized (various finish effects) and Galvanized Iron (industrial style).
Polyester (PE) Roller Coated Finish
Polyester roller coating is known for its cost-effectiveness and rich color options, making it suitable for both interior decoration and short-term outdoor projects. It provides a beautiful and diverse range of surface choices for budget-friendly designs.
PVDF Roller Coated Finish
PVDF roller coating provides a durable, weather-resistant finish at an excellent value. It’s a cost-effective solution ideal for long-lasting outdoor signage and mid-range building facades, balancing performance and budget.
Anodized Finish
Through pretreatments like brushing, bead blasting, and mirror polishing, combined with natural oxidation and electrolytic coloring, anodized finishes meet the demands of various advanced designs.
Galvanized Iron Finish
A zinc layer applied to a steel substrate creates the galvanized iron effect, commonly used in industrial-style designs.
Specifications
Technical Details
Benefits of ACM panels
Customizable, Tech-Savvy, AND SUSTAINABILITY IN ONE
ACM panels deliver superior performance with top-tier fire resistance, robust structural integrity, permanent flatness, and exceptional durability — engineered for safety and longevity in high-demand applications.
Grade-A fire resistance performance
The non-combustible core material can achieve an A2 fire rating, meeting the highest building fire protection standards.
Excellent structural strength
Strong wind and bending resistance, suitable for large-sized panels and high-rise curtain walls.
Ultimate flatness and stability
The surface remains permanently flat without bubbling or deformation.
Long service life
The inorganic core material is anti-aging and offers a lifespan matching that of buildings, lasting for decades.
Frequently Asked Questions (FAQs)
QUICK ANSWERS TO COMMON QUESTIONS
Have questions about working with ACM Panels? Browse our FAQs below for insights on materials, applications, and installation to help plan your project smoothly.
A1:Both consist of two aluminum sheets with a core. ACP typically uses an LDPE (plastic) core, making it lighter and easier to cut. ACM usually refers to panels with a mineral or fire-resistant core. ACM PANEL has a significantly higher fire resistance rating.
A2:Common uses include: High-end architectural curtain wall、Large-span building entrance、Interior decoration and functional partitions and sometimes used for Interior of vehicles.
A3:They are made of two aluminum sheets bonded to a mineral or fire-resistant core.
- For exterior walls and door frames: Total thickness should be at least 4mm, with surface thickness no less than 0.20mm.
- For interior or ceiling decoration: Total thickness is typically 3mm, with surface thickness no less than 0.15mm.
A5:Polyester (PE) Roller Coating, PVDF Roller Coating, Anodized、Galvanized Steel
A6:Solid colors (matte or glossy), aluminum natural finish、silvery white、champagne and Cinnabar red iron.
• Polyester (PE) Roller Coated: 3-5 years
• PVDF Roller Coated: 10-15 years
• Anodized: 15-20 years
• Galvanized Iron: over 20 years
Alloy:AA3003H24
Core:A2 FR core
Finish:PVDF Coated
Panel size:1220*2440mm
Total thickness:4mm
Skin thickness:0.50mm
A9:The A2 and B1 fire ratings achieved by Wise core materials comply with Chinese GB/T 8624 and EU EN 13501 standards.
For indoor use: adhesive, rivets, or screws.
For outdoor use: a frame-based dry hanging system is standard.
